For VirtualBox VM, I have the following network settings for my NICs. Do not use 'Bridged Adapter'. Do use 'Host-only Adapter' so you can set specific IP addresses. Make sure to use Adapter Type 'Intel PRO/1000 MT Server (8245EM)'.
NIC 1: MAC: 080027DC058B, Attachment: Host-only Interface 'VirtualBox Host-Only Ethernet Adapter', Cable connected: on, Trace: off (file: none), Type: 82545EM, Reported speed: 0 Mbps, Boot priority: 0, Promisc Policy: deny, Bandwidth group: none
NIC 2: MAC: 0800274003B8, Attachment: Host-only Interface 'VirtualBox Host-Only Ethernet Adapter', Cable connected: on, Trace: off (file: none), Type: 82545EM, Reported speed: 0 Mbps, Boot priority: 0, Promisc Policy: deny, Bandwidth group: none
NIC 3: MAC: 08002748C6D4, Attachment: Host-only Interface 'VirtualBox Host-Only Ethernet Adapter', Cable connected: on, Trace: off (file: none), Type: 82545EM, Reported speed: 0 Mbps, Boot priority: 0, Promisc Policy: deny, Bandwidth group: none
NIC 4: MAC: 0800276532D6, Attachment: Host-only Interface 'VirtualBox Host-Only Ethernet Adapter', Cable connected: on, Trace: off (file: none), Type: 82545EM, Reported speed: 0 Mbps, Boot priority: 0, Promisc Policy: deny, Bandwidth group: none
NIC 5: MAC: 080027EEF9D8, Attachment: Host-only Interface 'VirtualBox Host-Only Ethernet Adapter', Cable connected: on, Trace: off (file: none), Type: 82545EM, Reported speed: 0 Mbps, Boot priority: 0, Promisc Policy: deny, Bandwidth group: none
NIC 6: MAC: 08002762C4D5, Attachment: Host-only Interface 'VirtualBox Host-Only Ethernet Adapter', Cable connected: on, Trace: off (file: none), Type: 82545EM, Reported speed: 0 Mbps, Boot priority: 0, Promisc Policy: deny, Bandwidth group: none
This is what NICs look like after successful install of NetApp Sim 8.2.2 on VirtualBox:
c1::> net int show
(network interface show)
Logical Status Network Current Current Is
Vserver Interface Admin/Oper Address/Mask Node Port Home
----------- ---------- ---------- ------------------ ------------- ------- ----
c1
cluster_mgmt up/up 10.10.1.80/24 c1-01 e0c true
c1-01
clus1 up/up 169.254.17.11/16 c1-01 e0a true
clus2 up/up 169.254.210.87/16 c1-01 e0b true
mgmt1 up/up 10.10.1.81/24 c1-01 e0f true
vs1
c1-01_iscsi_lif_1
up/up 10.10.1.85/24 c1-01 e0c true
c1-01_iscsi_lif_2
up/up 10.10.1.86/24 c1-01 e0d true
vs1_admin_lif1
up/up 10.10.1.84/24 c1-01 e0e true
7 entries were displayed.
c1::> net port show
(network port show)
Auto-Negot Duplex Speed (Mbps)
Node Port Role Link MTU Admin/Oper Admin/Oper Admin/Oper
------ ------ ------------ ---- ----- ----------- ---------- ------------
c1-01
e0a cluster up 1500 true/true full/full auto/1000
e0b cluster up 1500 true/true full/full auto/1000
e0c data up 1500 true/true full/full auto/1000
e0d data up 1500 true/true full/full auto/1000
e0e data up 1500 true/true full/full auto/1000
e0f node-mgmt up 1500 true/true full/full auto/1000
6 entries were displayed.
Hope you follow link: http://community.netapp.com/t5/Simulator-Discussions/Simulate-ONTAP-8-1-1-withVirtualBox/m-p/2227 for insight to setup NetApp Sim on VirtualBox.
